General Information
Support:
Materials : ABS GF
Knob: PA6 + PP
RCU Support: POM
RCU Knobs: PA6
Metal parts and galvanised hardware
Temperature: +70°C -20°C
Product features:
This support is designed to provide a vertical grip on pieces such as blades/profiles, rollers, between 1 and 15 mm thick, minimum length 160 mm and the necessary clamping strength via two M4 grub screws.
The main feature of this support is its great versatility due to four possible adjustments despite its small size.
- Support rotation: the piece being gripped can undergo rotation from: -3 to +3 degrees by swivelling the base of the support, which has a reference guide.
- Piece rotation thanks to the RCU (Rotating Central Unit): the piece can be rotated by an angle of -15 to +15 degrees.
- Vertical: by 30 mm using the main knob.
- Horizontal: by adjusting the support fixing.
